คุณสมบัติ / Specifications
Function: 5/2
Connection Port Thread: G 1/2
Actuation Type: Solenoid/Solenoid
Manufacturer Series: 63
Mounting Style: Manifold
Number of Ports: 5/2
Body Material: Aluminium
Maximum Flow Rate: 4200L/min
Minimum Operating Pressure: 2bar
Maximum Operating Pressure: 8 bar
Thread Size: 1/2in
Minimum Operating Temperature: -10°C
Maximum Operating Temperature: +50°C
Thread Standard: G
-17%Sold out
สินค้าในกลุ่มนี้ทั้งหมด
Norgren Pressure Switch, G 1/4 25bar to 250 bar
Original price was: ฿12,389.80.฿9,911.84Current price is: ฿9,911.84. รวมภาษีมูลค่าเพิ่มแล้ว
Norgren G 1/4 Pneumatic Regulator - 0.3bar to 7bar, 1/4in, 20bar max. input – Model: R07-200-RNKG
Original price was: ฿3,074.88.฿2,562.40Current price is: ฿2,562.40. รวมภาษีมูลค่าเพิ่มแล้ว
Norgren 5/2 Pneumatic Solenoid Valve – Solenoid/Solenoid G 1/2 63 Series – Model: V63D511A-A3000
รหัสสินค้า: 533-7105Original price was: ฿13,885.40.฿11,571.17Current price is: ฿11,571.17. รวมภาษีมูลค่าเพิ่มแล้ว
โปรดติดต่อเราเพื่อสั่งซื้อ
สินค้าหมดแล้ว
รายละเอียดสินค้า / Product Details
**IMI Norgren Pneumatic Solenoid Valve, 8 Bar Maximum Operating Pressure, Manifold Mounting – V63 Series – V63D511A-A3000**
Want to take charge of your airflow? This pneumatic solenoid valve from IMI Norgren puts you in the driver’s seat. Use it to control the movement of air through a pneumatic system. A high maximum flow rate of 4200L/min means it’s suitable for large-scale setups such as food processing facilities. As it has a wide operating temperature range between -10°C and +50°C, it stands up to the challenges of industrial environments. For added safety, the unit comes with a manual override option.
**Features & Benefits**
• Compact dimensions of 35 (H) x 257 (L) x 65mm (W) ensure it fits neatly into busy systems
• Aluminium housing protects against corrosion and impact damage to maximise durability
• Light weight of 0.98kg puts little strain on your mounting surface
**Applications**
• Industrial automation
• Material handling
• Conveyor belts
• Water treatment systems
