3RG6232-3LS00-PF, Pepperl + Fuchs Ultrasonic Sensor Barrel 50 → 300 mm Analogue, 4-Pin M12 Connector – Model: 3RG6232-3LS00-PF

คุณสมบัติ / Specifications Detection Range: 50 → 300 mm Output Type: Analogue Body Style: Barrel Thread Size: M18 x 1 Transducer Frequency: 400kHz Diameter: 18 mm Maximum DC Voltage: 30V Supply Voltage: 12 → 30 V dc Terminal Type: 4-Pin M12 Connector IP Rating: IP67 Housing Material: Nickel Plated Brass Length: 104mm Switching Frequency: 5 Hz Switching Current: 150 mA Maximum Operating Temperature: +70°C Minimum Operating Temperature: -25°C Dimensions: 104 x 18 mm
